SV736 UV-Readable Resin Thermal Transfer Ribbon
Sunavin SV736 is a specialty resin-based thermal transfer ribbon formulated with UV-sensitive pigments, making it ideal for invisible or covert printing applications where information must remain hidden under normal light but become visible under ultraviolet (UV) exposure.
It prints sharp, secure images on a variety of synthetic label stocks, and features excellent resistance to smudging, abrasion, and chemicals. With good compatibility on both coated papers and films, SV736 is a preferred solution for industries requiring anti-counterfeiting, compliance marking, or hidden traceability.
Categories: Resin Ribbon
Product Details
- Product Name: SV736 UV-Readable Resin Thermal Transfer Ribbon
- Ribbon Width: 25mm – 300mm (customizable)
- Ribbon Length: Up to 1000 meters (standard)
- Coating Options: Coated Side Out (CSO) and Coated Side In (CSI)
- Core Types: 1 inch, 1/2 inch, notched and unnotched
- Compatible Printers: Zebra, TSC, Avery, Datamax, and other major brands
- Color Options: Black
typical applications
Retail & E-commerce
Industrial & Manufacturing
Electronics
Automotive & Chemicals
Healthcare & Pharmaceuticals
Special Use
recommended substrates
ribbon properties
| PET Film Thickness | 4.8±0.3 μm |
| Ribbon Thickness | 6.2±0.3 μm |
| Ink Layer Thickness | 1.4±0.3 μm |
| Color | Black |
| Compatible Printhead | Flat Head |
printing performance
| Darkness | N/A |
| Sharpness | 90 % |
| Transfer Sensitivity | 80 % |
| Print Speed | 50.8 mm/s (2 ips) |
| Energy Setting | Low to Medium |
| Melting Point | 70 ℃ |
printing quality
0° Barcode
90° Barcode
Sharpness
Graphics
ribbon resistance
storage conditions
| Temperature | 5°C - 35°C（41°F - 95°F） |
| Humidity | 20% - 80% （RH） |
| Direct sunlight | |
| Avoid | High temperature & humidityhigh |
| Exposure to chemicals |
certifications & approvals
Common Ribbon Sizes and Applications
| Length x Width | Core Size | Typical Applications |
| 30m x 40mm (1.57" width) | 12.7mm (0.5") | Compact desktop printers (TSC TTP-244, etc.) |
| 74m x 110mm (4.33" width) | 12.7mm (0.5") | Zebra GK420T, TLP2844; standard desktop label printing |
| 300m x 110mm (4.33" width) | 25.4mm (1") | Industrial printers like Zebra ZT230, TSC ME240 |
| 360m x 110mm (4.33" width) | 25.4mm (1") | High-capacity desktop or semi-industrial |
| 450m x 110mm (4.33" width) | 25.4mm (1") | Zebra ZT410/411, Sato CL4NX - standard industrial use |
| 600m x 110mm (4.33" width) | 25.4mm (1") | Extended print runs, logistics labeling |
| 600m x 153mm (6.02" width) | 25.4mm (1") | Large label printing (e.g., pallet labels) |
| 900m x 153mm (6.02" width) | 76mm (3") | Heavy-duty industrial labeling and warehousing |
| 450m x 55mm (2.17" width) | 25.4mm / 38mm | TTO coding (food/medicine packaging), small format |
| 600m x 60mm (2.36" width) | 25.4mm / 38mm | TTO or small industrial printers with higher yield |
| 1000m x 110mm (4.33" width) | 76mm (3") | Custom long-run labels, high-volume users |
| 1200m x 153mm (6.02" width) | 76mm (3") | Very large format printers, custom rewinder systems |
